Mic Input Balanced XLR-F - Combo Line Input Balanced TRS Jack USB
Ingressi :
6 MIC - 4 Line - 2 stereo line - USB
Sensibilità ingresso :
Mic Input from 0 to -60 dB Line Input from +20 to -40 dB
Impedenza di ingresso :
Mic Input 2 Kohm Line Input 10 Kohm
Connettori di uscita :
Balanced TRS Jack and / or XLR-M - USB
Uscite :
C\ROOM - MAIN MIX - ALT 3-4 - AUX 1 & 2 - PHONES - USB
Uscite amplificatore :
2 x SPEAKON
Livelli di uscita :
MAIN MIX nom. out level +4 dBu - all other outputs 0 dBu - Maximum level all outputs +22 dBu
Impedenza uscita cuffia :
min. impedance 32 ohm - max. out level (2x) 193 mW
Distorsione (THD+N) :
at +4dB, 1kHz < 0,008 %
Equalizzazione canale ingresso mono :
Lo Cut 75 Hz, 18 dB/oct. HIGH (shelving) ±15 dB @ 12KHz MID (peaking) ±15 dB @ 2.5KHz LOW (shelving) ±15 dB @ 80Hz
Equalizzazione canale ingresso stereo :
HIGH (shelving) ±15 dB @ 12KHz MID (peaking) ±15 dB @ 2.5KHz LOW (shelving) ±15 dB @ 80Hz
Effetti incorporati :
HALL, ROOM, VOCAL and PLATE reverbs, MONO, STEREO and TAP DELAY, CHORUS and FLANGER, REV + DELAY, REV + CHORUS and REV + FLANGER 16 step PRESET selector 16 step VARIATION selector PEAK LED MUTE and TAP DELAY switch with LED indicator and footswitch
Fattore di smorzamento :
>300 @ 4 ohm
Assorbimento massimo :
400VA
Risposta in frequenza :
20Hz - 20kHz (+/- 0.5dB)
Rumore :
unweighted < -93 dBu
Protezioni :
DC voltage, short circuit, thermal, soft start
Raffreddamento :
variabile speed DC fan
Peso Netto :
5.7 kg(12.568lb )
Dimensioni (L x A x P) :
28 x 12.5 x 35.2 cm
Note tecniche :
Borsa per il trasporto e adattatori 19” rack inclusi
